型號 |
MODEL |
LE-3200E |
|
|
特性 |
CHARACTERISTIC |
AUTOMATIC &
Supersonic
Coalescence |
|
適用材質 |
APPLICABLELASTICCLOTH |
PP NON-WOVEN BAGS |
|
布面積 |
CAPACITY OF BAG |
3200mm |
|
放布直經 |
Max Diameter of Cloth
Roll |
800 mm |
|
放料 |
Desbobinador |
6psc |
|
收料 |
Rebobinador |
1psc |
|
產量 |
PRODUCTION CAPACITY |
20-60 m/min |
|
型態 |
TYPE |
REEL to REEL |
|
超音波 |
Supersonic |
1200w 20hz X7 |
|
額定馬力 |
Installed Power |
12HP |
|
折邊寬度 |
SIDE FOLDING WIDTH |
150MM X2 |
|
耗電量 |
POWER COMSUMPTION |
18.6KW |
|
包裝 |
PACKING |
STANDARD
Bar iron fixation
PALLET& 1X40"x2 CONTAINER |
|
人力 |
MAN POWER |
2 PERSONS |
|
空氣壓縮機 |
Air Compressor |
2HP, 1 unit |
|
裝櫃尺寸 |
CUBAGE ARK |
2X40"尺 |
|
機械尺寸 |
MACHINE DIMENSION |
L10300xW3800xH1550MM(N.W3850KGS) |
THE SPECIFICATIONS AND SIZES MENTIONED IN THIS LEAFLET ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE |
Lung - Ye Machinery Co.,Ltd. NO:9Pei Liao Road,Ma Yuan Village,Tzi Tong County,Yunlih Hsien,Taiwan. TEL: +886-5-584-6851 FAX: +886-5-585-0074 http://www.lungye.com.tw E-mail:lye@lungye.com.tw |
